Four Head Automatic Net Weight Liquid Filling Machine delivers the highest levels of automation, precision filling performance and throughput in a full-featured 4 head package.Automatic PLC-controlled
4-Head Net Weight Filler & Sealer with Lateral Transfer System
150 Containers/Min ? ±0.02% Accuracy ? Pint-to-Pail Flexibility ? 40% Faster Cycle Times
| Parameter | QF-1210 (Standard) | QF-1220X (ATEX) | QF-1230H (High-Visc) |
|---|---|---|---|
| Capacity Range | 0.5L-20L (±0.02%) | 0.5L-20L (±0.03%) | 0.5L-20L (±0.025%) |
| Throughput | 150 Containers/Min | 135 Containers/Min | 120 Containers/Min |
| Accuracy | ±0.02% Gravimetric | ±0.03% | ±0.025% |
| Container Types | Pints ? Quarts ? Gallons ? Pails<br>Glass/Plastic/Metal | Same + Safety Cans | Same + Composite Drums |
| Filling Technology | Quad Coriolis Mass Flow | ATEX Gear Pumps | Heated Screw Auger |
| Lateral Transfer | Linear Servo Rail<br>? 0.5s Transfer Time<br>? ±0.1mm Positioning | Same + Pressurized | Same + High-Temp Belt |
| Sealing Methods | Crimp ? Screw Cap ? Induction Seal | Snap Lid + ATEX Seal | Tamper-Evident Band |
| Material Contact | 316L EP (Ra<0.2μm) | Hastelloy C276 | Ceramic-Coated Path |
| Cycle Time | 0.4s/Container | 0.45s/Container | 0.5s/Container |
| Power | 480V/60Hz, 18kW | 24VDC Ex ia | 480V/60Hz, 22kW |
| Certifications | NTEP Class 0.2 | ATEX Zone 1 | FDA 21 CFR 177.2600 |
| Footprint (L×W) | 4.5m×2.2m | 4.8m×2.4m | 4.6m×2.3m |
Performance Metrics:
| Metric | QF-1210 | Conventional Rotary |
|---|---|---|
| Transfer Time | 0.5s | 1.2-1.8s |
| Positioning Accuracy | ±0.1mm | ±0.5mm |
| Acceleration | 5G | 2G |
| Component | Innovation | Performance |
|---|---|---|
| 4-Channel Flow | Cross-Calibrated Coriolis Meters | ±0.01% Head Variance |
| Smart Tare | AI-Container Weight Prediction | ±0.005% Tare Accuracy |
| Seal Force Control | Real-Time Thickness Compensation | ±0.8% Torque Consistency |
Chemicals & Lubricants
| Feature | ATEX Solution |
|---|---|
| Vapor Control | Nitrogen Blanketing (O?<0.3%) |
| Static Dissipation | Ionized Air Curtain (10? ions/cm3) |
| Corrosion Resistance | Hastelloy C276 Path |
Food & Beverage
Hygienic Design:
Oxygen Barrier:
| Technology | Performance |
|---|---|
| N? Flushing | O?<0.1% Headspace |
| Vacuum Sealing | -0.8bar Residual Pressure |
Industrial Adhesives
| Challenge | Solution |
|---|---|
| Stringing | Laser Cutoff + Vacuum Suction |
| Settling | In-line Dynamic Agitator |
| Skin Formation | Continuous Surface Scraper |
1. Container Infeed → 2. Lateral Transfer to Filling Station → 3. 4-Head Net Weight Filling (±0.02%) → 4. HyperShift? to Sealing Station → 5. AI-Guided Crimping/Capping → 6. Lateral Transfer to Outfeed → 7. 100% Vision Inspection
Cycle Time: 0.4 seconds/container
Lateral Transfer Superiority:
? 40% Faster Cycles: - Linear Servo Rail (5G Acceleration) - 0.5s Station Transfer - 0.1mm Positioning Repeatability ? Quad-Head Precision: | **Component** | **Performance**| |----------------------|------------------------| | Coriolis Meters | ±0.01% of Reading | | Auto-Tare System| ±0.005% Container Weight | | Density Compensation | Real-Time Temp/Viscosity Adjustment | ? Industrial Durability: - Tungsten Carbide Rails (2,200 Hv) - IP69K Washdown Protection - 100,000-Hour MTBF
| Model | Target Application | Key Feature |
|---|---|---|
| QF-1210 | Chemicals/Lubricants | NTEP Class 0.2 Accuracy |
| QF-1220X | Flammable Liquids | ATEX Zone 1 Pressurized |
| QF-1230H | Adhesives/Sealants | 80°C Heated Path + Anti-Skinning |
? ATEX 2014/34/EU Zone 1 (QF-1220X) ? FDA 21 CFR 177.2600 ? NTEP Certificate 21-051 (Class 0.2) ? EHEDG EL Class I ? ISO 9001:2015
Shell Lubricants Case Study:
*"After implementing QF-1210:
Throughput: 85 → 150 containers/min (+76%)
Accuracy: ±0.18% → ±0.015%
Cycle Time: 0.7s → 0.4s (-43%)
ROI: 3.8 months"*
Game-Changing Efficiency:
? Lateral Transfer Advantage: - 40% Faster Than Rotary Indexing - Zero Container Rotation (No Spillage) - 5G Acceleration (Industry's Fastest) ? Quad-Head Power: | **Metric** | **Performance**| |---------------------|------------------------| | Fill Speed | 5L/sec Total Flow| | Output Capacity| 9,000 Containers/Hour | | Uptime | 99.6%| ? Future-Ready Design: - OPC UA Connectivity - Digital Twin Integration - AI-Predictive Maintenance
